Rebel FAT Series

from
€6,069.00



VAT, shipping etc.

  • Basic characteristics

The Rebel FAT is the upgraded version of the Wild One FAT primarily designed to keep up with ever growing demand for motor assisted trikes.  The Rebel FAT is built for all type of terrain. An ultimately universal trike sharing the already proven unique suspension, handling and steering. Rebel FAT is available in different wheel size configurations: 20/20 and 20/26

The tricycle supports a maximum weight of 150 kg, including the operator and baggage.

  • Short description
The Rebel FAT is the high-torque "Off-Road Tank" of the Steintrikes lineup. Built with oversized tubing specifically to handle the relentless power of E-Assist motors, it is the most rigid and stable platform for extreme heavy-duty expeditions through deep sand and arctic snow.

The pictures are informative only and may vary from actual product
Contact Us

The Rebel FAT is designed to solve the biggest challenge of fat-triking: the immense rolling resistance of oversized tires. By utilizing larger diameter tubing ( wall), the Rebel frame provides the extreme torsional stiffness required to tame high-torque Mid-Drive E-motors. When the motor engages to push through deep snow or sand, the oversized frame eliminates "frame-flex," ensuring 100% of the power reaches the ground. This rigidity also provides a rock-solid feel during high-speed E-assisted descents. It is not just a trike; it is a specialized E-performance vehicle for the most demanding environments on Earth.  Rebel FAT is available in different wheel size configurations: 20/20 and 20/26

FRONT WHEELS: 20" x 4.0"

REAR WHEEL: 20" or 26"x4.0"

SUSPENSIONS: 100mm travel on all wheels

WHEELBASE: 1180-1255mm

OVERALL WIDTH: 880 mm

TRACK WIDTH: 805 mm

GROUND CLEARANCE: 175 mm

SEAT HIGHT (mesh/shell): 350/280 mm

TOTAL LENGHT (unfolded): 2015-2105 mm

FOLDED LENGHT: 1750-1900 mm

BB HEIGHT: 465 mm

PAYLOAD:  (Rider + Luggage)
