Rebel Plus 24/24

from

€5,627.00

VAT, shipping etc.

Basic characteristics

While the front remains locked into the high-clearance 24" setup, the Rebel Plus features a modular rear geometry that allows you to tailor the trike to your specific riding environment:

24" Rear (The Torque Specialist): Creates a symmetrical 24/24/24 footprint. This setup provides the best mechanical advantage for steep, technical E-climbing and offers the most compact, agile handling for off-road trails.
26" Rear (The Universal Explorer): A perfect hybrid configuration. The 26" rear wheel opens up a massive selection of E-bike rated tires and offers a smoother roll over mixed terrain while maintaining excellent stability.
28" / 700c Rear (The High-Speed Cruiser): Optimized for the open road. The larger 28" wheel maximizes momentum and rolling efficiency, making it the ideal choice for long-distance commuting and S-Pedelec configurations.

Short description

Modern mid-drive motors deliver instant, explosive torque that can cause standard frames to "flex" or twist under load. The Rebel Plus is the definitive answer to this challenge. The chassis is designed for an effortless "entry and exit" position, making it highly practical for daily use or long-distance touring.

The pictures are informative only and may vary from actual product

By utilizing larger diameter tubing, the Rebel Plus provides the torsional rigidity necessary to handle the explosive power of modern mid-drive motors. Where standard frames might flex under the strain of high-torque E-assist, the Rebel remains rock-solid, ensuring that every watt of power—both yours and the motor's—is translated directly into forward motion.

With its 100mm of full suspension and increased ground clearance, the Rebel Plus isn't just a trike; it is a safe, comfortable, and indestructible "chassis for the future" of electric cycling.

The tricycle supports a maximum weight of 150 kg, including the operator and baggage.

FRONT WHEELS: 24" (507 mm) – Fixed size for high ground clearance and roll-over

REAR WHEEL: 24" (507 mm), 26" (559 mm), or 28" / 700c (622 mm)

SUSPENSION SYSTEM: Full Suspension, 100 mm on all three wheels

WHEELBASE: 1130-1255mm

OVERALL WIDTH: (Road/OffRoad): 840/880 mm

TRACK WIDTH: 785/805 mm

GROUND CLEARANCE: 123-193 mm

SEAT HIGHT (mesh/shell): 230-350 mm

TOTAL LENGHT (unfolded): 1865-2055 mm

FOLDED LENGHT: 1600-1790 mm

BB HEIGHT: 415 mm
